Machine Feature

1. Two spindles simultaneously process two pieces of the same product, doubling the efficiency.

2. Save money – if the processed products need to add the fourth axis, compared to 2 sets of four axes to 2 machine tools, you can save a set of money for the fourth axis.

3. Save space – compared to 2 machine tools, save space.

4. Save workers – compared to 2 machine tools, the operator is reduced. The more machines, the more obvious the saving

Machine Specification

ITEM	UNIT	TS640	TS860	TS1065
Three axis travel(X/Y/Z1(Z2))	mm	600/400/450(450)	800/600/650(650)	1000/650/600(600)
Spindle nose to worktable distance	mm	200-650mm	200-850	200-800
Dimensions of table (L x W)	mm	700×420	1300×500	1300×600
Maximum load	kg	500	800	1000
T-slot number x slot width x spacing		3x18x125	5x18x100	5x18x100
Spindle speed	rpm	10000	8000	8000
Spindle taper		BT40/Ø120	BT40/Ø160	BT40/Ø150
Spindle motor power	kW	5.5/7.5	7.5/11	7.5/11
Center distance of two spindles	mm	380	480	700
Fast moving speed (X/Y1(Y2)/ z-axis)	m/min	48/48/48	48/48/48	48/48/48
Cutting feed rate	mm/min	1-10000	1-8000	1-8000
Tools qty	Pcs	16*2=32	24×2=48	24×2=48
Tool exchange time (tool-tool)	S	2.5	2.5	2.5
Positioning accuracy (X/Y/Z)	mm	±0.005/300	±0.005/300	±0.005/300
Repeated positioning accuracy (X/Y/Z)	mm	±0.003/300	±0.003/300	±0.003/300
Power	kVA	40	60	60
Machine weight	kg	6000	8500	9500
